تايتشو Kayond الماكينات والشركة المحدودة
| مكان المنشأ: | جيانغسو ، الصين ، CN ؛ JIA |
|---|---|
| اسم العلامة التجارية: | KAD |
| الحد الأدنى لكمية: | 1 |
| الأسعار: | $1,300-1,400 |
| طول الشوكة: | 1070mm/مخصصة | عرض الشوكة: | 550/680 مم/مخصصة |
|---|---|---|---|
| مركز التحميل: | 500 ملم | وزن الحمولة: | 1500 كجم |
| جهد البطارية: | 24 فولت | سعة البطارية: | 80 أمبير |
| ارتفاع الحمولة: | 3000mm | نوع الصاري: | 2 مرحلة / 3 مرحلة |
| وضع القيادة: | ووكي ستير | مصدر الطاقة: | محرك العاصمة |
| ارتفاع الرفع الأدنى: | 1580 ملم | الأبعاد العامة: | 1770 ((L) * 850 ((w) * 1580 ((h) |
| وزن: | 500 كجم | سرعة القيادة: | 5.0/5.0 مم/ثانية |
| سرعة رفع: | 140/135 مم/ثانية | ||
| إبراز: | 1.5 ton electric pallet stacker,electric pallet stacker 3000mm lift,24V battery pallet stacker,electric pallet stacker 3000mm lift,24V battery pallet stacker |
||
| Attribute | Value |
|---|---|
| Condition | New |
| Fork Length | 1070mm/customized |
| Fork Width | 550/680mm/customized |
| Applicable Industries | Hotels, Garment Shops, Building Material Shops, Machinery Repair Shops, Manufacturing Plant, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction works, Energy & Mining, Food & Beverage Shops, Advertising |
| Terrain Adaptability | Indoor Flooring, Outdoor Pavement, other |
| Load Center | 500 mm |
| Load weight | 1500KG |
| Battery | 24V/80Ah |
| Battery type | Lead acid battery |
| Load height | 3000mm |
| Warranty | 1 Year/2000 Working Hours |
| Mast | 2 Stage/3 Stage |
| Loading Capacity | 1500kg |
| Drive mode | Walkie Steer |
| Power Source | DC MOTOR |
| Machinery Test Report | Provided |
| Video outgoing-inspection | Provided |
| Warranty of core components | 1 Year |
| Core Components | Pressure vessel, motor, Bearing, Gear, Pump, Gearbox, Engine |
| Min. Lifting Height | 1580mm |
| Overall Dimensions | 1770(L)*850(w)*1580(h) |
| Weight (KG) | 500 kg |
| MODEL | CDDW12 CDDW16 | |||
|---|---|---|---|---|
| Drive system | Battery | |||
| Driving mode | Walkie | |||
| Load Capacity | Q | KG | 1200/1600 | |
| Load Center | MM | 500 | ||
| Weight(With battery) | CDDW12 | KG | 470/485/505/520 | |
| CDDW16 | KG | 495/510/532/553 | ||
| Wheels Material | PU | |||
| Lifting Height | H3 | MM | 1600/2000/2500/3000 | |
| Lowest Mast | H1 | MM | 2080/1580/1830/2080 | |
| Max.Height when operating | H4 | MM | 2080/2730/3230/3730 | |
| Min.Height of Fork | H13 | MM | ≤90 | |
| Length | L | MM | 1770 | |
| Width | B | MM | 850 | |
| Fork Length | L1 | MM | 1070 | |
| Wheelbase | Y | MM | 1250 | |
| Fork Outside Width | B1 | MM | 680 | |
| Fork Inside Width | B2 | MM | 305 | |
| Min.Turning Radius | WA | MM | 1390 | |
| Driving Speed (Empty/Full Load) | MM/S | 5.0/5.0 | ||
| Lifting Speed (Empty/Full Load) | MM/S | 140/135 | ||
| Descending Speed (Empty/Full Load) | MM/S | 150/155 | ||
| Max.Gradient (Empty/Full Load) | % | 7/5 | ||
| Brake | Electromagnetic | |||
| Driving Motor | KW | DC/0.75 | ||
| Lifting Motor | KW | DC/2.2 | ||
| Battery Capacity | V/Ah | 24*70/24*80Ah | ||
| Noise level DIN 12053 | DB | ＜70 | ||
Domestic famous control handle with functional buttons that can control UP/DOWN, FORWARD/BACKWARD sensitively. Uses Curtis brand accelerator to ensure safe operating.
Combined with the key, battery indicator, and emergency switch. Functional panel with beautiful design makes work joyful and easy.
Strong cylinder and chain ensure smooth fork operation. Available with 1-stage, 2-stage, or 3-stage mast options.
